Additional information
| U/M | Each |
|---|---|
| Composition | 316 Stainless Steel Formed |
| Finish | High Polished |
Man Ship 316 SS Formed Round Opening Portlights | LSR
Man Ship 316 SS Formed Round Opening Portlights | LSR
Features
- 316 Stainless steel formed frame for high grade strength and corrosion resistance
- Watertight
- Tempered glass
- Straight spigot only
- Standard spigot size “G” sizes available: 1-1/4″, 1-1/2″, 2″, 2-1/2″, 3″, 3-1/2″
- Custom spigot size “G” available from 1″ – 5″
- Available with storm cover
- Fixed versions available
| PART NO. | C | E | GLASS THK | SPIGOT “G” |
|---|---|---|---|---|
| LSR-07-GS | 7-1/4″ | 9-5/8″ | 5/16″ | Specify when ordering |
| LSR-08-GS | 8-1/4″ | 10-5/8″ | 5/16″ | Specify when ordering |
| LSR-10-GS | 10-3/8″ | 12-7/8″ | 3/8″ | Specify when ordering |
| LSR-12-GS | 12-3/8″ | 14-7/8″ | 3/8″ | Specify when ordering |
| LSR-14-GS | 14-3/8″ | 16-7/8″ | 3/8″ | Specify when ordering |
The spigot is the section on the back of the portlight that extends through the hull or cabin wall. When calling or emailing, please specify your spigot size “G”.
Standard sizes: 1-1/4″, 1-1/2″, 2″, 2-1/2″, 3″, 3-1/2″. Need a different size? Custom orders available from 1″– 5″.
Standard sizes: 1-1/4″, 1-1/2″, 2″, 2-1/2″, 3″, 3-1/2″. Need a different size? Custom orders available from 1″– 5″.
Custom Order Portlights: Click Here
Installation Guide:
Drawings:
Installed
